Product Series & Specifications

Material Grade:

Inconel Series: Inconel 600 (N06600) - General corrosion and high-temperature strength; Inconel 625 (N06625) - High strength, superior resistance to pitting/crevice corrosion and fatigue.

Incoloy Series: Incoloy 800 (N08800) - Good oxidation and carburization resistance at high temperatures; Incoloy 800H/HT (N08810/N08811) - Improved high-temperature strength and creep properties; Incoloy 825 (N08825) - Excellent resistance to acids (sulfuric, phosphoric), pitting, and crevice corrosion; Incoloy 840 (N08840) - Superior high-temperature oxidation and sulfidation resistance.

Other High-Performance Alloys: Depending on demand, we can provide plates/sheets of Hastelloy (e.g., C-276, C-22), Monel, Nimonic, etc.

Size Range:

Thickness: Available with a range from 0.5mm (0.02") to 150mm (5.9").

Width: custom widths are supported.

Length: custom lengths are supported.

Applicable Standards:

ASME SB / ASTM B Series (Primary Standards):

ASTM B168 / ASME SB-168: (Inconel 600 Plate/Sheet/Strip)

ASTM B443 / ASME SB-443: (Inconel 625 Plate/Sheet/Strip)

ASTM B409 / ASME SB-409: (Incoloy 800, 800H, 800HT Plate/Sheet/Strip)

ASTM B424 / ASME SB-424: (Incoloy 825 Plate/Sheet/Strip)

ASTM B575 / ASME SB-575: (Nickel-Chromium-Molybdenum Alloys like Hastelloy C-276, C-22 Plate/Sheet/Strip)

AMS (Aerospace Material Specifications): For example, AMS 5540 (Inconel 625 Sheet/Strip, Solution Annealed), AMS 5590 (Inconel 600 Sheet/Strip, Solution Annealed).

Other International General Standards: GB/T, JIS, DIN, GOST, ISO, etc.

Surface Finish: Available in hot-rolled annealed and pickled, cold-rolled annealed bright, mechanically ground, polished, or other surface conditions to meet specific application requirements for corrosion resistance, weldability, or aesthetics.

Manufacturing Process & Quality Control

High-Quality Melting & Rolling: Utilizing advanced vacuum melting (VIM/VAR/ESR) technologies to produce high-purity nickel-based alloy ingots. Subsequently, through rigorously controlled hot rolling and precision cold rolling processes, we ensure the plate's density, uniformity, and excellent mechanical properties.

Precision Heat Treatment: Implementing precise solution annealing and/or aging treatments to relieve processing stress, optimize grain structure, and ensure the material's creep strength, oxidation resistance, and ultimate service performance.

High-Precision Processing & Cutting: Offering precision cutting services (laser, waterjet, plasma, shearing) and flattening/leveling services, ensuring accurate plate dimensions and superior edge quality.

Rigorous Quality Testing (INSPECTIONS):

Raw Material Inspection: Strict chemical composition analysis (Spectro Test), including precise control over trace impurities and alloy element content.

Internal Flaw Detection: Ultrasonic Testing (UT) is performed on finished plates/sheets to ensure the absence of internal cracks, inclusions, delaminations, and other defects.

Geometric Dimensions & Visual Inspection: Precise measurement of thickness, width, length, flatness, and high-precision visual and automated inspection for surface defects (e.g., scratches, indentations, oxide scale).

Mechanical Properties Testing: Tensile Test (Elongation, Yield Strength, Tensile Strength, including high-temperature tensile), Hardness Test, Impact Test, Bend Test, Creep Test (as required), Fatigue Test (as required).

Corrosion Testing: Corrosion tests in specific corrosive media (e.g., ASTM G28, G48, G35, G36) are performed to verify durability in harsh chemical environments.

Metallographic Analysis: Evaluation of grain size and microstructure to ensure conformity with standards and final application requirements.

Traceability: Comprehensive material reports are provided, ensuring complete traceability from raw material to final plate/sheet, with support for independent third-party certification.

Why Choose Our Nickel-based Alloy Plates / Sheets?

Extensive Experience: Specialized in the R&D and manufacturing of high-performance nickel-based alloy plates/sheets for over 19 years, accumulating vast technical expertise and rigorous quality control experience in high-temperature alloy rolling, precise alloy composition control, and extreme environment material applications.

Superior Melting & Rolling: Utilizing advanced vacuum melting (VIM/VAR/ESR) technologies to produce high-purity nickel-based alloy ingots. Subsequently, through rigorously controlled hot rolling and precision cold rolling processes, we guarantee the plate's density, uniformity, and excellent mechanical properties.

Quality Assurance: All products are accompanied by comprehensive test reports, and independent third-party certifications (e.g., TUV, SGS, BV, Lloyd's Register) are readily available upon request, to ensure product quality strictly conforms to relevant standards and is committed to exceeding customer expectations.

ISO 9001:2015 Certified Facility: Strictly adhering to international quality management systems, we rigorously follow high standards and pursue continuous improvement at every step from raw material procurement to finished product delivery.

Customized Services: Whether for standard dimensions and grades or custom nickel-based alloy plates/sheets based on customer drawings and specific requirements (e.g., special alloy compositions, unique dimensions, specific surface conditions), we are committed to providing exclusive solutions.

Flexible Procurement & Stock: No strict minimum order quantity (MOQ) limit, respecting every user's purchasing requirements; common raw materials or finished products are kept in stock to expedite supply.

Test Samples Available: Free test samples can be provided for select products. According to company policy, customers are responsible for sample shipping costs.
