Material Grades:

Commercially Pure (CP) Titanium Series: GR1, GR2, GR3, GR4 .(offering excellent corrosion resistance, good formability, and weldability)

Titanium Alloy Series: GR5 (TC4, Ti-6Al-4V) (with high tensile strength). GR7 (molybdenum-containing titanium alloy, with stronger corrosion resistance). GR9 (Ti-3Al-2.5V) (with higher strength and lower density). GR11, GR12, GR23 (Biocompatible Ti-6Al-4V ELI) (this material contains a lower oxygen content, has better biocompatibility). GR10, GR16, GR17 and more are also available.

ERTi Welding Wire Grades: ERTi-1, ERTi-2, ERTi-3, ERTi-4, ERTi-5, ERTi-7, ERTi-9, ERTi-11, ERTi-12, ERTi-23

Manufacturing Standards:

Primary Standard: ASTM B863 (Standard Specification for Titanium and Titanium Alloy Wire).

Biomedical Material Standards: ASTM F136 (Standard Specification for Wrought Titanium-6Aluminum-4Vanadium ELI Alloy for Surgical Implant Applications), ASTM F67 (Standard Specification for Unalloyed Titanium, for Surgical Implant Applications).

Welding Standards: AWS.A5.16 (Specification for Titanium and Titanium Alloy Welding Electrodes and Rods).

Other General Standards: ASTM B348 , ASME SB348, GB/T3623-2007 (Chinese standard for titanium wire), JIS (Japanese Industrial Standards), DIN (German Institute for Standardization), GOST (State Standard of the Russian Federation), ISO (International Organization for Standardization), etc.

Size Range:

Diameter: From 0.05mm to 4mm or customizable.

Length & Packaging: Typically supplied in coils, on spools, or as straightened cut lengths. Customizable lengths and spooling weights are available.

Surface Finish:

Available in pickled, bright annealed, polished, ground, or black/oxidized states to meet specific application requirements for dimensional accuracy, surface roughness, or appearance.

Cutting/Fabrication Services:

We offer precision services for titanium wire, including straightening, precise cutting (to specific lengths), spooling/coiling (to custom weights), and various forming/winding operations to meet your unique needs.

Manufacturing Process & Quality Control

Advanced Wire Forming Processes:

High-Quality Raw Materials: Utilizing high-purity titanium sponge and alloy elements, produced through advanced vacuum melting technologies  to create high-purity titanium ingots, ensuring the quality of the wire's material source.

Precision Wire Forming: Titanium wire is manufactured through rigorously controlled hot rolling and precision cold drawing and/or cold rolling processes . This optimizes grain structure and ensures superior density, uniformity, and excellent mechanical properties, especially for ultra-fine gauges.

Controlled Heat Treatment: Implementing precise annealing (including multi-pass vacuum annealing), solution treatment, and/or aging treatments to relieve processing stress, optimize grain structure, and ensure the material's ductility, strength, and long-term stability in use.

High-Precision Finishing: Offering turning, grinding, polishing, and other finishing services to ensure precise diameter dimensions and surface finish, meeting high-precision application demands.

Rigorous Quality Testing (INSPECTIONS):

Raw Material Inspection: Strict chemical composition analysis (e.g., Spectro Test) of titanium sponge and alloy elements.

In-Process Quality Testing: We conduct strict testing of dimensions, strength, corrosion resistance, and other indicators on each batch of products during production.

Internal Flaw Detection: Ultrasonic Testing (UT) and/or Eddy Current Testing (ET) are performed on finished wire (especially for welding wire or critical applications) to ensure the absence of internal cracks, inclusions, porosity, and other defects.

Geometric Dimensions & Visual Inspection: Precise measurement of diameter, length, straightness, ovality, and high-precision visual and automated inspection for surface defects (e.g., scratches, indentations).

Mechanical Properties Testing: Tensile Test (Elongation, Yield Strength, Tensile Strength), Hardness Test, Impact Test, Bend Test, and Torsion Test (crucial for wire), ensuring material meets precise mechanical requirements.

Metallographic & Cleanliness Testing: Metallographic Analysis to evaluate grain size and microstructure. Cleanliness Testing for special applications (e.g., medical, electronics).

Corrosion Testing: Corrosion tests in specific corrosive media are performed to verify durability in harsh chemical environments.

Complete Traceability: We provide a full material report for each batch, ensuring complete traceability from raw material to final wire, with support for independent third-party certification upon request.
