Product Series & Specifications

Main Forms:

Round Bars/Rods: The most common form. Diameter (φ):  6mm - 500mm.

Rectangular Bars: For specific structural or processing needs.

Square Bars: Used for fasteners, shafts, etc.

Hexagonal Bars: Used for fasteners requiring wrenching, etc.

Hollow Bars/Rods: For weight reduction or components requiring internal passages.

Custom Shapes: Unique bar shapes can be provided according to customer drawings.

Material Grade:

Commercially Pure Zirconium: Zr1 (R60700, CP1), Zr3 (R60702, CP2), Zr4 (R60704, CP4) - Excellent corrosion resistance.

Zirconium Alloys: Zr5 (R60705, Zr-Nb 2.5%) - Enhances strength, creep resistance, and high-temperature oxidation resistance compared to pure zirconium, especially suitable for nuclear-grade and high-strength structural applications.

Size Range:

Diameter/Side Length: Available in a range from  φ6mm to  φ500mm.

Length: Up to L≤12000mm (12 meters); customizable as required.

Applicable Standards:

Primary Standard: ASTM B550 (Standard Specification for Zirconium and Zirconium Alloy Bar and Wire).

Nuclear Application Standard: ASTM B496 (Standard Specification for Zirconium and Zirconium Alloy Bar, Rod, and Wire for Nuclear Applications).

Raw Material Standards: ASTM B350 (Zirconium and Zirconium Alloy Ingots), ASTM B493 (Forgings, if used as raw material).

Other International General Standards: GB/T, JIS, DIN, GOST, ISO, etc. (specific numbers available upon request).

Surface Finish: Available in black forged, machined, ground, polished, pickled, or other surface conditions to meet specific application requirements for dimensional accuracy, surface roughness, or appearance.

Manufacturing Process & Quality Control

High-Purity Melting & Bar Forming: Utilizing advanced vacuum melting (VAR/EB Melting) technology to produce high-purity zirconium ingots. Subsequently, zirconium bars are manufactured through rigorously controlled forging, hot rolling, and precision cold drawing and/or cold rolling processes, ensuring their density, uniformity, and superior mechanical properties.

Precision Heat Treatment: Implementing precise annealing treatments to relieve processing stress, optimize grain structure, and ensure the material's ductility, mechanical properties, and long-term stability in use.

High-Precision Machining: Offering turning, grinding, polishing, and other machining services to ensure precise bar dimensions and surface finish, meeting high-precision application demands.

Rigorous Quality Testing (INSPECTIONS):

Raw Material Inspection: Strict chemical composition analysis (Spectro Test), including control over trace impurities.

Internal Flaw Detection: Ultrasonic Testing (UT) and Eddy Current Testing (ET) are performed on finished bars to ensure the absence of internal cracks, inclusions, porosity, and other defects.

Geometric Dimensions & Visual Inspection: Precise measurement of diameter, length, straightness, ovality, and high-precision visual and automated inspection for surface defects (e.g., scratches, indentations).

Pressure Testing: Hydrostatic testing or pneumatic testing.

Mechanical Properties Testing: Tensile Test (Elongation, Yield Strength, Tensile Strength), Hardness Test, Impact Test, Bend Test, etc.

Metallographic Analysis: Evaluation of grain size and microstructure to ensure conformity with standards and final application requirements.

Corrosion Testing: Corrosion tests in specific corrosive media (e.g., ASTM G28, G48) are performed to verify durability in harsh chemical environments.

Nuclear-Grade Performance Testing:  Low thermal neutron capture cross-section testing can be performed.

Traceability: Comprehensive material reports are provided, ensuring complete traceability from raw material to final bar/rod, with support for independent third-party certification.

Why Choose Our Zirconium Bars / Rods?

Extensive Experience: Specialized in the R&D and manufacturing of high-quality zirconium bars/rods for over 19 years, accumulating vast technical expertise and rigorous quality control experience in nuclear-grade materials processing, extreme corrosion environment materials, and precision bar manufacturing.

Superior Melting & Processing: Utilizing advanced Vacuum Arc Remelting (VAR) or Electron Beam (EB) Melting ensures high-purity and dense zirconium ingots. Through precision forging, hot rolling, and cold drawing/cold rolling processes, we guarantee the bar's grain structure, dimensional accuracy, and superior performance.

Quality Assurance: All products are accompanied by comprehensive test reports, and independent third-party certifications (e.g., TUV, SGS, BV, Lloyd's Register) are readily available upon request, to ensure product quality strictly conforms to relevant standards and is committed to exceeding customer expectations.

ISO 9001:2015 Certified Facility: Strictly adhering to international quality management systems, we rigorously follow high standards and pursue continuous improvement at every step from raw material procurement to finished product delivery.

Customized Services: Whether for standard dimensions and grades or custom zirconium bars/rods based on customer drawings and specific requirements (e.g., special purity, unique dimensions, shape, surface condition), we are committed to providing exclusive solutions.

Flexible Procurement & Stock: No strict minimum order quantity (MOQ) limit, respecting every user's purchasing requirements; common raw materials or finished products are kept in stock to expedite supply.

Test Samples Available: Free test samples can be provided for select products. According to company policy, customers are responsible for sample shipping costs.
