Our Product Range & Parameters

Material Grades:

Pure Titanium Series:

Gr1, Gr2, Gr3, Gr4 (Offering excellent corrosion resistance and good formability, ideal for general corrosion-resistant or non-structural applications).

Titanium Alloy Series:

Gr5 (Ti-6Al-4V, known for high strength and lightweight properties), Gr7 (enhanced corrosion resistance with Palladium), Gr9 (Ti-3Al-2.5V, good strength and formability), Gr10, Gr11, Gr12 (excellent crevice corrosion resistance), Gr16, Gr17, Gr23 (Biocompatible Ti-6Al-4V ELI), etc.

Manufacturing Standards:

Seamless Square/Rectangle Tubes:

Primarily traceable to ASTM B861, ASME SB861 (for seamless titanium pipe) and ASTM B338, ASME SB338 (for seamless titanium tube, often used as raw material for cold forming).

Welded Square/Rectangle Tubes:

Primarily traceable to ASTM B338, ASME SB338 (for welded titanium tube), with raw materials traceable to ASTM B265 (Titanium and Titanium Alloy Plate, Sheet, and Strip).

Other International General Standards:

JIS (Japanese Industrial Standards), DIN (German Institute for Standardization), GOST (State Standard of the Russian Federation), ISO (International Organization for Standardization), etc.

Size Range:

Outer Dimensions (Side Lengths): Customizable.

Wall Thickness: Various wall thicknesses are available,  to meet diverse structural and fluid handling requirements. Please inquire for specific ranges.

Length: custom lengths are supported.

Surface Finish: Available in pickled, bright annealed, polished, or other finishes as per application requirements.

Connection Type: Typically butt-welded or mechanically joined for structural applications.

Manufacturing Process & Quality Control

Advanced Forming Processes:

Produced through cold forming (from seamless round tubes) or precision welding (from high-quality titanium plates). These techniques help ensure excellent dimensional accuracy, straightness, and material integrity.

High-Precision Machining:

Utilizing advanced CNC (Computer Numerical Control) equipment to ensure precise cuts, end finishes, and overall dimensional conformity.

Rigorous Quality Testing (INSPECTIONS):

Raw Material Inspection: Chemical Composition Analysis (Spectro Test).

Geometric Dimensional Inspection: Visual Inspection, precise measurement of side lengths, wall thickness, straightness, corner radii, and twist.

Mechanical Properties Testing: Yield and Tensile Strength, Elongation, Hardness, Flattening Test, Flaring Test.

Non-Destructive Testing (NDT)： Eddy Current Test, Ultrasonic Testing (UT), Hydrostatic Test, Pneumatic Test (for sealed structures).

Traceability: Comprehensive material reports and third-party certificates are available upon request.

Why Choose Our Titanium Square / Rectangle Tubes?

Our Expertise:

Extensive Experience: Focused on titanium profile R&D and manufacturing for over 19 years, accumulating vast industry experience and professional knowledge in structural applications, corrosive environments, and lightweight, high-strength designs.

Superior Material Properties: Fully leveraging titanium's inherent superior corrosion resistance, high strength-to-weight ratio, and good biocompatibility.

Quality Assurance: All products are accompanied by comprehensive test reports, and independent third-party certifications are readily available upon request, to ensure product quality meets relevant standards.

ISO 9001:2015 Certified Facility: Strictly adhering to international quality management systems, we rigorously follow high standards and continuous improvement at every step from raw material procurement to finished product delivery.

Customized Production: Whether for standard dimensions or specific side lengths, wall thicknesses, or application requirements, we are committed to providing exclusive custom solutions based on your drawings and precise needs.

Flexible Procurement: No strict minimum order quantity (MOQ) limit, respecting every user's purchasing requirements.

Test Samples Available: Free test samples can be provided for select products. According to company policy, customers are responsible for sample shipping costs.
