Our Product Range & Parameters

Material Grades:

Commercially Pure (CP) Titanium Series: Gr1, Gr2, Gr3, Gr4 (offering high ductility, excellent corrosion resistance, and good weldability, suitable for chemical linings, battery electrodes, precision stamped parts).

Titanium Alloy Series: Gr5 (Ti-6Al-4V, high strength, for aerospace structures), Gr7 (enhanced crevice corrosion resistance), Gr9 (Ti-3Al-2.5V, combining good strength with formability), Gr11, Gr12 (excellent resistance to acids and reducing media), Gr23 (Biocompatible Ti-6Al-4V ELI, for medical implants), etc.

Manufacturing Standards:

General Standard: ASTM B265 / ASME SB265 (Standard Specification for Titanium and Titanium Alloy Plate, Sheet, and Strip).

Aerospace Standard: AMS 4911 (Ti-6Al-4V Alloy Sheet/Strip/Plate, Annealed).AMS 4919 (Ti-6Al-4V Alloy, Solution Heat Treated, Aged ）

Biomedical Standards: ASTM F136 (Standard Specification for Wrought Titanium-6Aluminum-4Vanadium ELI (Extra-Low Interstitial) Alloy for Surgical Implant Applications), ASTM F67 (Standard Specification for Unalloyed Titanium, for Surgical Implant Applications).

Other International General Standards: JIS (Japanese Industrial Standards), DIN (German Institute for Standardization), GOST (State Standard of the Russian Federation), ISO (International Organization for Standardization), etc. (specific numbers available upon request).

Size Range:

Thickness: Available with a range from 0.5mm (0.0196") to 12mm (0.47") for precision titanium coil/strip.

Width: Custom narrow strips or slitting are supported.

Length: Typically supplied in coil form; custom lengths are available upon request, meeting continuous production needs.

Coil Inner/Outer Diameter & Weight: Standard coil inner diameters (e.g., 508mm) and outer diameters, as well as various coil weights, can be provided, facilitating integration into automated production lines.

Edge Condition: Available with Mill Edge, Slit Edge, Deburred Edge, etc.

Surface Finish: Available in pickled, bright annealed, cold-rolled polished, or custom surface conditions to meet specific optical, bonding, or welding requirements.

Manufacturing Process & Quality Control

Advanced Rolling Processes: Utilizing advanced hot rolling for robust plate formation and multi-roll precision cold rolling processes to achieve excellent surface finish, strict thickness tolerances, and optimized mechanical properties for sheets and strips.

Controlled Heat Treatment: Implementing multi-pass vacuum annealing or protective atmosphere annealing treatments, which helps to ensure good flexibility, ductility, and stable performance of titanium coil/strip in subsequent processing and actual applications by optimizing material grain structure and relieving internal stresses.

High-Precision Slitting & Edge Processing: Employing high-precision slitting equipment to ensure precise strip width, and offering various edge treatments to meet customers' specific requirements for edge quality.

Rigorous Quality Testing (INSPECTIONS):

Raw Material & In-Process Inspection: Chemical Composition Analysis, precise thickness and width measurement (online and offline), high-precision visual and automated detection of surface defects (pinholes, scratches).

Mechanical Properties Testing: Tensile Strength, Yield Strength, Elongation, Hardness, Bend Test, etc.

Metallographic & Corrosion Testing: Metallographic Analysis (for microstructure evaluation), Corrosion Test for specific applications.

Traceability: Comprehensive material reports are provided, ensuring complete traceability from raw material to finished product, with support for independent third-party certification.
