Titanium plate parameters

Our Product Range & Parameters

Material Grades:

Commercially Pure (CP) Titanium Series: Gr1, Gr2, Gr3, Gr4 (offering excellent corrosion resistance, good formability, and weldability, suitable for general corrosion-resistant or non-structural applications).

Titanium Alloy Series: Gr5 (Ti-6Al-4V, known for high strength and lightweight properties), Gr7 (enhanced crevice corrosion resistance), Gr9 (Ti-3Al-2.5V, combining good strength with formability), Gr11, Gr12 (excellent resistance to acids and reducing media), Gr16, Gr17, Gr23 (Biocompatible Ti-6Al-4V ELI), etc.

Manufacturing Standards:

Primary Standard: ASTM B265 (Standard Specification for Titanium and Titanium Alloy Plate, Sheet, and Strip).

Biomedical Material Standard: ASTM F136 (Standard Specification for Wrought Titanium-6Aluminum-4Vanadium ELI (Extra-Low Interstitial) Alloy for Surgical Implant Applications).

Aerospace Material Specifications (AMS): AMS 4900 (CP Titanium Sheet/Strip/Plate), AMS 4901 (CP Titanium Plate), AMS 4911 (Ti-6Al-4V Sheet/Strip/Plate), AMS 4919 (Ti-6Al-4V Alloy, Solution Heat Treated, Aged), AMS 4914 (Ti-6Al-4V Sheet/Strip/Plate, Annealed).

Other International General Standards: JIS (Japanese Industrial Standards), DIN (German Institute for Standardization), GOST (State Standard of the Russian Federation), ISO (International Organization for Standardization), etc. (specific numbers available upon request).

Size Range:

Thickness: Available with a range from 0.5mm (0.02") to 100mm (4").

Width (W) & Length (L): supported upon request to minimize material waste and optimize your project.

Surface Finish: Available in pickled, bright annealed, polished, or other finishes as per application requirements.

Cutting/Fabrication Services: We offer precision cutting (laser, waterjet, plasma, shearing) and custom fabrication services.

Manufacturing Process & Quality Control

Advanced Rolling Processes: Utilizing advanced hot rolling for robust plate formation and cold rolling for superior surface finish, tighter tolerances, and enhanced mechanical properties of sheets.

Precise Heat Treatment: Controlled annealing, solution treatment, and aging processes are performed to optimize material microstructure, relieve internal stresses, and achieve desired mechanical properties.

High-Precision Fabrication & Cutting: Employing advanced CNC (Computer Numerical Control) equipment to ensure precise cuts, edge finishes, and overall dimensional conformity.

Rigorous Quality Testing (INSPECTIONS):

Raw Material & In-Process Inspection: Chemical Composition Analysis (Spectro Test), and monitoring during rolling processes.

Geometric Dimensional Inspection: Visual Inspection, precise measurement of length, width, thickness, flatness, and surface defects.

Non-Destructive Testing (NDT): Ultrasonic Testing (UT) for internal flaw detection, Eddy Current Test (where applicable).

Mechanical Properties Testing: Tension Test (Elongation, Yield Strength, Tensile Strength), Impact Test, Hardness Test, Bend Test.

Metallurgical & Corrosion Tests: Metallographic Analysis (for microstructure evaluation), Intergranular Corrosion Test (where applicable), Corrosion Test (e.g., ASTM G28/G48).

Traceability: Comprehensive material reports and full traceability are provided, with support for independent third-party certification.

Why Choose Our Titanium Plate / Sheet?

Our Expertise:

Extensive Experience: Focused on titanium plate and sheet R&D and manufacturing for over 19 years, accumulating vast industry experience and professional knowledge in structural applications, corrosive environments, and lightweight, high-strength designs.

Superior Material Properties: Fully leveraging titanium's inherent superior corrosion resistance, high strength-to-weight ratio, and good biocompatibility.

Quality Assurance: All products are accompanied by comprehensive test reports, and independent third-party certifications (e.g., TUV, SGS, BV, Lloyd's Register) are readily available upon request, to ensure product quality meets relevant standards.

ISO 9001:2015 Certified Facility: Strictly adhering to international quality management systems, we rigorously follow high standards and continuous improvement at every step from raw material procurement to finished product delivery.

Customized Production: Whether for standard dimensions or specific width, length, or application requirements, we are committed to providing exclusive custom solutions based on your drawings and precise needs.

Flexible Procurement & Stock: No strict minimum order quantity (MOQ) limit, respecting every user's purchasing requirements; a substantial stock of common specifications is maintained to meet some immediate needs.

Test Samples Available: Free test samples can be provided for select products. According to company policy, customers are responsible for sample shipping costs.
